EcoFlex 00-10

Unit Size	Net Weight
Pint Kit	2 lb
Gallon Kit	16 lb
Five Gallon Kit	80 lb



Ecoflex 00-10 is a very soft, very strong and very "stretchy" platinum cure rubber. Ecoflex¨ rubbers are based on Smooth-On's Dragon Skin¨ technology and are currently available in five different hardness': Shore A-5, Shore 00-10, 00-20, 00-30, 00-35 and 00-50. They are suitable for a variety of applications including making prosthetic appliances, cushioning for orthotics and special effects applications (especially in animatronics where repetitive motion is required).

Technical Properties

Mix Ratio by Weight	1A:1B
Mix Ratio by Volume	1A:1B
Pot Life	30 minutes
Cure Time	4 hours
Color	Translucent
Shore Hardness	00-10
Mixed Viscosity	14,000 cps
Shrinkage	< .001 in./in.
Specific Volume	26.6 cu. in./lb.
Specific Gravity	1.04g/cc
Useful Temperature (max)<	450¼F
Useful Temperature (min)<	-65¼F
Tensile Strength	120 psi
100% Modulus	8 psi
Elongation @ Break	800%
Die B Tear Strength	22 pli



Ecoflexª Rubbers are platinum-catalyzed silicones that are versatile and easy to use. Ecoflexª Rubbers are mixed 1A:1B by weight or volume and cured at room temperature with negligible shrinkage. Rubber also cures without a "tacky" surface. Low viscosity ensures easy mixing and de-airing, or you can choose to mix and dispense using our convenient dispensing cartridges. Cured rubber is very soft, very strong and very "stretchy", stretching many times its original size without tearing and will rebound to its original form without distortion. Ecoflexª Rubbers are water white translucent and can be color pigmented with SILC Pig© pigments for creating a variety of color effects. You can also add Smooth-On's "Silicone Thinner" to further lower the viscosity or add Smooth-On's "Thi-Vex" thickening agent for brush-on application.
